3D Flexible Welding Platform Fixture

The 3D flexible welding platform fixture is a modular, multi-functional advanced tooling system. The platform uses high-strength cast iron or steel as its base, and the worktable surface is equipped with a standardized D16/D28 series grid hole system, supporting arbitrary adjustment and positioning in the X, Y, and Z dimensions.

The system is equipped with standardized support, clamping, positioning, and locking components, allowing for rapid assembly of a dedicated fixture conforming to the workpiece contour without welding or machining. It represents a shift from traditional “single dedicated tooling” to “flexible adjustable tooling,” significantly shortening the preparation cycle, reducing manufacturing costs, and ensuring welding accuracy and consistency. It is widely used in automotive manufacturing, construction machinery, rail transportation, and robotic automated welding, providing an ideal solution for meeting the needs of multi-variety, small-batch, high-precision welding production.
